.jpg)
|
Model |
Power(KW) |
Current (A) |
Capacitors (μF) |
Max Head (m) |
Max.Capacity (L/min) |
Inlet/Out（Inch） |
Maximum suction (m) |
Capacity l/min |
||||||
|
kW |
HP |
5 |
10 |
20 |
30 |
40 |
50 |
|||||||
|
JET-60L |
0.55 |
0.75 |
2.4 |
12 |
40 |
42 |
1"X1" |
8 |
37 |
33.5 |
28 |
22 |
18 |
|
|
JET-80L |
0.8 |
1 |
3.7 |
16 |
48 |
48 |
1"X1" |
8 |
44 |
40 |
34.5 |
30.5 |
26.8 |
|
|
JET-100L |
1 |
1.3 |
4.6 |
20 |
52 |
54 |
1"X1" |
8 |
48 |
44.5 |
39.5 |
36 |
32 |
13 |
|
JET-110L |
1.1 |
1.5 |
4.9 |
20 |
54 |
54 |
1"X1" |
8 |
51 |
48 |
42.5 |
38.8 |
35 |
24 |
Overall & Installation Dimensions
.gif)
|
Model
|
Frame Dimensions(mm) |
Weight (kg) |
Packing size (mm) |
Packing |
|||||||||||||
|
a |
f |
h |
H1 |
H2 |
W1 |
W2 |
n |
n1 |
g |
s |
NW |
GW |
L |
W |
H |
20'Cont |
|
|
JET-60L |
143 |
425 |
196 |
98 |
156 |
79 |
55 |
182 |
142 |
9 |
11 |
14.3 |
15.3 |
480 |
210 |
220 |
1340 |
|
JET-80L |
143 |
425 |
196 |
98 |
156 |
79 |
55 |
182 |
142 |
9 |
11 |
14.7 |
15.7 |
480 |
210 |
220 |
1340 |
|
JET-100L |
143 |
425 |
196 |
98 |
156 |
79 |
55 |
182 |
142 |
9 |
11 |
15.9 |
16.9 |
480 |
210 |
220 |
1340 |
|
JET-110L |
143 |
425 |
196 |
98 |
156 |
79 |
55 |
182 |
142 |
9 |
11 |
16.4 |
17.4 |
480 |
210 |
220 |
1340 |
